Cooling Fan With Filter

Ush 45,000

Product SKU : VF FLTR-0150-CF

Availability : In Stock





Our fans are widely used in the control panels, junction boxes, power distribution box, automation equipment, electronic and power device, welding machine, packing etc.

 Additional Information

Model VF FLTR-0150-CF
Power Supply 230VAC
Item Dimensions (mm) 125×125×25
Air Flow Rate (free blow) (m3 /h) 96/112
Air Flow Rate (with Mat) (m3 /h) 65
Power Consumption (W) 16
Current Consumption (A) 0.08
Current Consumption (A) 39/42
Axial fan, ball bearing service life L10 at +40°C (+104°F): min. 37,000 h fan body aluminium, rotor metal
Connection 2 stranded wires, 160mm
Enclosure cut-out 125×125+1 mm
Mounting frame Fast Fixing with clips for different size thickness of cabinet and enclosure, no need screw fxing
Filter mat G4 acc. to DIN EN 779, filtering degree 94%
Filter material New ABS material confirm to RoHS, Fireproof or not fireproof can be chosen
Operating/Storage temperature 25 to +65°C (-13 to +149°F) / -40 to +70°C (-40 to +158°F)
Operating/Storage humidity max. 90% RH (non-condensing)
Protection type/Protection class IP54 / I (earthed)
Additional Normally airflow direction is Out, if you need airflor direction In, when placing an order, kindly mention.
